High Speed Doors

Everything you need before specifying a rapid door — how they cut energy loss and downtime, what they cost, how to pick the right one for a cold store, food plant or logistics site, and what to hand your architect for spec.

4 m/s

Top opening speed vs a standard roller door

20–50%

Typical cut in energy loss at a cold store opening

1M+

Cycles, engineered for sites that never stop

Blue Ulti Frigo 2 high speed freezer door installed in a warehouse.

What Is a High Speed Door?

A high speed door is a powered industrial door — usually a flexible PVC curtain or rigid insulated panel — built to open and close far faster than a conventional door. A standard sectional or roller door moves at around 0.5 m/s. A high speed door travels at 2 to 4 m/s, so a 3 metre opening clears in about a second.

That speed is the whole point. Every second a door sits open, conditioned air escapes, dust and pests get in, and traffic backs up behind it. Less time open means stable temperatures, fewer defrost cycles and forklifts that don’t queue — which is why high speed doors (also called rapid doors, rapid roll doors or high speed roller shutter doors) are standard in food processing, cold storage and logistics.

Behind the speed sits the same core technology across the range: a light curtain, a high-torque drive, hands-free activation, and a safety system that stops the door before it touches anything. For the full walkthrough, see our plain-English guide.

How Do High Speed Doors Work?

Activation: A motion sensor, radar, pull cord or access system triggers the door — hands-free, so traffic keeps moving without contact contamination.

High-Speed Drive: A high-torque motor drives the curtain at 2 to 4 m/s, ramped smoothly to cut wear and noise over hundreds of thousands of cycles.

Curtain & Seals: A reinforced or insulated curtain runs in side guides with brush or lip seals — closed, an effective barrier to air, dust, noise and pests.

Safety & Self-Repair: Light grids and safety edges stop the door on contact. Breakaway curtains pop out and reset after a forklift hit — a knock doesn’t become a callout.

Watch an Ulti Roll high speed door in action

90 seconds - activation to full open, back to sealed

The Benefits of Rapid Roller Doors

One door, six problems solved. Here’s what each one means for your site and your bottom line.

Lower energy bills

Less air exchange means stable temperatures, fewer defrost cycles and lower refrigeration run time — money straight back on the power bill.

Higher throughput

No waiting at the door. Forklifts drive through without stopping and dock-to-store flow smooths out without adding staff.

Audit-ready hygiene

Sealed zones and hands-free activation keep bacteria, dust and airborne contamination where they belong.

Fewer site incidents

Photocells and safety edges stop the door before it touches anything, cutting forklift and pedestrian risk.

Less impact damage

Self-repairing curtains take a forklift hit and reset — your building, stock and door all survive the shift.

Pest exclusion

Birds, rodents and insects need an opening and a few seconds. A fast-closing door and bug shield mesh take both away.

PROJECTS

Real Results From NZ Operations Teams

PRODUCT RANGE

The Ulti Group High Speed Door Range

Seventeen models, grouped by the application they’re built for. Most sites end up with a mix.
Green rapid acting door with clear vision panels in a warehouse

Ulti Roll Door

View Product

Not sure which door is right? Jump to how to choose or talk to a specialist →

Specifying a Project?

CAD, BIM and spec sheets for architects and designers

Every door in the range comes with downloadable CAD and BIM files, wind-class and U-value data, and clearance drawings — so it drops straight into a build spec. Our team will also mark up shop drawings for a specific opening on request.
Before we quote, have on hand: Headroom & side-room at the opening · wall/structure type · power supply · control & BMS integration needs · required safety systems

Mistakes to Avoid When Buying a High Speed Door

The wrong door costs more in downtime and re-work than the right one costs upfront. A few things worth checking before you sign off.

Buying on speed alone

The fastest door isn't the right door if it isn't rated for your cycle count, wind zone or temperature.

Undersizing the opening

A door sized to today's forklift fleet is a bottleneck the day you upgrade equipment.

Skipping insulation to save upfront

On a temperature-controlled opening, the energy loss usually costs more than the insulated door within a couple of years.

Ignoring service and spare parts

A great door with no local support turns a minor fault into days of downtime waiting on parts.

Missing automation requirements

Conveyor and BMS integration needs to be specified up front — retrofitting controls after install adds cost and delay.

Not asking about warranty terms

Standard warranty length, what it covers, and what voids it vary a lot between suppliers — worth confirming before you buy.

How to Choose the Right High Speed Door

Answer these questions and the shortlist writes itself.

What's on either side of the opening?

Same climate both sides, an ambient interior door will do. Different temperatures, look at the freezer range. A clean zone next to production, look at the food processing range.

How big is the opening?

Under 4 × 4 m suits almost any model. Between 4 and 8 m is Ulti Roll or EX5 territory. Over 8 m wide or 5 m high means Ulti Fold or a bi-parting setup.

Is it exposed to weather?

External openings on windy sites need Class 4 or Class 5 wind resistance — Ulti EX5, Ulti Fold, or an Ulti Roll with high-wind retention guides.

How many cycles a day?

Under 100, standard configuration. 100 to 500, high-cycle bearings and controllers. Over 500, go EX5 or Spiral and put it on a maintenance plan.

What temperature does it need to hold?

Ambient, any everyday door. Chiller, DuoTherm or Flex. Freezer to −30°C, DuoTherm Blast or FasTrax FR. Automated freezer conveyor lines, the Ulti High Speed Conveyor Door.

Is food safety involved?

Then food-grade PVC and stainless frames aren’t optional — Ulti Roll Food, Ulti Roll Clean or Ulti Roll Air.

Do you need security when it's closed?

Ulti Komby gives you a rapid door and a roller shutter on one opening. Ulti Spiral gives you insulated aluminium slats.

How Much Do High Speed Doors Cost in NZ?

What they cost

A standard interior Ulti Roll starts around $12,000–$18,000 plus GST, supplied and installed. Larger, freezer-rated or external doors run from $25,000 up. Price is driven by size, environment, wind zone, insulation and site access.

Install time

One to five days per door on a straightforward site once the wall, power and clearance zones are ready. Multi-door projects are scheduled to overlap so your operation keeps running.

Lifespan

Ten to fifteen years and beyond with proper servicing. We have freezer doors still running clean after seven years on high-cycle sites.

Most suppliers sell you a door and move on. Ulti Care keeps it running.

Preventative maintenance scheduled around your cycle rate, 24/7 nationwide callouts, and parts for all makes and models — so the door that saves you money on day one keeps saving it for the next fifteen years. A typical Ulti Care Protect plan cuts unplanned callouts and adds years of asset life.
